CabSafe™ Light Curtain System

The CEDES CabSafe light curtain system fulfills all door detection code requirements, and then some. A 2D light curtain and a 3D time-of-flight (TOF) sensor provide continuous detection in a clearly defined and stable area. This includes when the door is in the fully open position and prior to the initial of a close. Conveniently, the CabSafe controller brings the connections of all these powerful devices into a single location and outputs are either FSSL or serial communication.

The systems are designed for and can be used in center-opening as well as left or right side-opening elevator applications and is suitable for dynamic as well as static installations. CabSafe is not subject to upcoming FCC limitations of frequency bands that currently allows UWB for interference protection.

Get a quote

CabSafe 3D features

  • State-of-the-art 3D infrared image sensor for true 3D protection
  • Reliable detection of people and objects in front of the cab using TOF technology
  • Reduces risk of accidents caused by being hit by doors
  • Reduces risk of damage caused by objects hitting doors
  • Fulfills detection requirements of ASME A17.1-2019 / CS B44-19
  • Ideal for both new installations and modernization
  • Flush and surface mounting options available

CabSafe 2D features

  • Ideal for both static and dynamic installations
  • Criss-cross beams for a reliable detection
  • Meets ASME A17.1-2019/CS B44-19 code detection requirements
  • Meets all requirements under EN81-20

Popular CabSafe part numbers

  • A850-471 – CabSafe 2D and 3D black, flush mount system
  • A850-472 – CabSafe 2D and 3D SS transom mount system
