Safe-T-Lock Door Monitor

• Fault types detected: door not fully closed, shorted door lock, car gate switch and hardware failure for redundant protection
• Complies with Section 3.10.12 of the New York City Building Code
• CSA approved to CSA B44.1 and ASME A17.5
• PLC-based design includes a display screen to indicate monitor status and specific door fault codes for troubleshooting
• Includes terminal block system for easy interfacing with existing elevator controllers
• Works with most controllers on the market
• Eight interface relays address variability in system voltages

Small programmable logic controller used to:

• Monitor for shorts across door lock and car gate switch circuits
• Detect door position and failure modes of the Door Monitor (e.g., failed input relays and signals)
• Prevent the car from running once a fault is detected

Public safety

Reduces injuries and/or fatalities related to elevator movement by preventing car from moving if the car door is not closed. Car is prevented from moving if:

1. Car door contact is closed, or the circuit is bypassed
2. Interlock contact on hall door that is coupled to the opened car door is closed or the circuit is bypassed
3. Car door and interlock contact to the opened car door are closed or the circuit is bypassed

Liability reduction

Enhanced elevator safety systems help demonstrate due care for riders in case of accidents.

Code compliant

No need to modernize the entire system when / if the jurisdiction adopts ASME 17.3-2015 for existing elevators and escalators.
